Diamond Core Drill Machine
Z1Z-CF02-205
Quantity
Q: Can you do OEM or ODM?
A: Yes, OEM and ODM are accecpted and supported.
A: Yes, OEM and ODM are accecpted and supported.
Q: How long is your delivery time?
A: Generally it is 7 days if the products are in stock. It will be 15-30 days if you want to customize your products.
Q: Do you provide samples?
A: Yes, we are very happy to offer you the samples, however I am afraid that we need to charge you for the samples and delivery fees.
Q: What is your terms of payment?
A: We accept T/T, other methods are negotiable.
Q: What's the package of machine?
A: We have different packages for machines, such as plastic case, honeycomb composite box, carton box or pallets depending on your requests.
Q: Can I purchase the products which are not shown on the website?
A: Yes, please send us your detailed information and we are wlling to help with your requirements.
A: Generally it is 7 days if the products are in stock. It will be 15-30 days if you want to customize your products.
Q: Do you provide samples?
A: Yes, we are very happy to offer you the samples, however I am afraid that we need to charge you for the samples and delivery fees.
Q: What is your terms of payment?
A: We accept T/T, other methods are negotiable.
Q: What's the package of machine?
A: We have different packages for machines, such as plastic case, honeycomb composite box, carton box or pallets depending on your requests.
Q: Can I purchase the products which are not shown on the website?
A: Yes, please send us your detailed information and we are wlling to help with your requirements.
APPLICATIONS and Advantages:
·For core drilling in walls, floors, roofs and road surface, up to Ø205 mm.
·Suitable for various materials such as reinforced concrete, brick and otherconstruction materials.
·For deep pdle drilling, plumbing, electrical installation etc.
·Different drilling speed version for appropriate situations.
·Electric leakage protection.
·Replaceable Stand options can provide further functions such as angleand stitch drilling
| Z1Z-CF02-205 | Z1Z-CF02-205B2 | Z1Z-CF02-205C | Z1Z-CF02-205D2 | |
| Maximum diameter | Φ205mm（for concrete） | Φ205mm（for concrete） | Φ205mm（for concrete） | Φ205mm（for concrete） |
| Input power | 2400W | 2400W | 2400W | 2400W |
| Rated voltage | 110/220/240V | 110/220/240V | 110/220/240V | 110/220/240V |
| Frequency | 50Hz | 50Hz | 50Hz | 50Hz |
| No load speed | 750 r/min | 750 r/min | 750 r/min | 750 r/min |
| Package Size | 87.1X37.1X25.6 cm | 107.1X37.1X37.8cm | 100.1X31.5X43.8 cm | 104.1X36.1X39.8 cm |
| Pcs/Carton | 1PC | 1PC | 1PC | 1PC |
| N.W/G.W | 21/26 KG | 31/35 KG | 25/31 KG | 32/37 KG |
